Features
◆   steel structure, split transport, easy to operate;
◆   configuration control system completely offline, the operation is more humane;
◆   adjustable laser mounting bracket supports different types of lasers to install and use;
◆   modular design, interchangeability strong;
◆   new optimized optical design, the optical path is more stable;
◆   with a new electrical design, selection of superior electrical components to ensure the stability of the system;

Applications Industry
Clothing, leather, advertisement decoration, gifts, paper products, wood products, electronic appliances, lighting, packaging, platemaking, commodity model, shadow carving and so on.

Application materials
All kinds of fabrics, leather, glass, plastic, PVC, paper, wood and bamboo, rubber, resin, ceramic, granite and other non-metallic.

Technical Parameters

Laser power	60W/80W/100W/130W	Laser cooling	Water-cooled
Laser wavelength	10.64μm	Working speed	0～30m/min
Supply voltage	AC220V±10%	Operating temperature	0～45℃
Repeatability	≤±0.05mm	Working humidity	5%～95%

Machine type

Machine type	Processing area（mm)	Size（mm)	Machine type	Processing area（mm)	Size（mm)
YT6040	600×400	1170×910×1000	YT1280	1200×800	1770×1360×1100
YT960	900×600	1470×1110×1100	YT1480	1400×800	1970×1360×1100
YT1060	1000×600	1570×1140×1100	YT1610	1600×1000	2170×1560×1100
YT1390	1300×900	1870×1440×1100	YT1810	1800×1000	2370×1560×1100
